Winnipeg Deck Railings

Privacy Wall
Installation Guide

Playlist

Post & Rail Setup

Install posts securely, measure carefully, and cut rails to fit with proper angles.

Our posts come precut to 42” or 36” railing,  One of our specialists will review your plan drawing and packing slip with you. When your materials arrive, check to make sure you have everything. If anything is missing or you have questions, contact us right away.

Tools Checklist

10 min

Impact Driver

$140

Power Drill

$198

Concrete Drill

$219

Clamps

$35

Composit Shims

$30

Level

$15

Measuring Tape

$10

Non-ferrous Blade

$33

Square

$14

Mitre Saw

(with non-ferrous blade)
$140

One of our specialists will review your plan drawing and packing slip with you. When your materials arrive, check to make sure you have everything. If anything is missing or you have questions, contact us right away.

Tools Checklist

10 min

Impact Driver

$140

Power Drill

$198

Concrete Drill

$219

Clamps

$35

Composit Shims

$30

Level

$15

Measuring Tape

$10

Non-ferrous Blade

$33

Square

$14

Mitre Saw

(with non-ferrous blade)
$140

  • Review Materials: Make sure they match what came on your invoice and site layout.
  • Fasten brackets onto each post.
  • Insert Rubber Gasket: Insert rubber gasket into channel groove and make sure it is fully seated along entire length. Press firmly into place.
  • Fasten Post to Deck.
  • Insert Planks In Between Posts: Slide plank between vertical posts, and push firmly until fully seated. Check alignment on both ends.
  • Fasten Planks Onto Brackets:  Making sure everything in level, fasten plank against bracket.
  • Go over the entire railing system and check if you missed any loose screws, notice if there are any scratches.
  • Step back to admire a job well done.
Download Privacy Wall Installation Guide

Troubleshooting Guide

Common issues and solutions from our installation experts

  Posts feel wobbly after installation
  • Posts feel wobbly after installation
  • Consider adding bracing between posts for extra stability
  • Drill hole at new angle
  • Use a hammer drill with carbide-tipped masonry bit
  • Clear debris frequently by pulling bit out while drilling
  • Use proper drilling technique: don't force, let tool do the work
  • Double-check that all posts are plumb and level
  • Measure twice, adjust posts before final tightening
  • Use adjustable rail brackets if available
  • Consider professional consultation for complex layouts
  • Start with smaller pilot hole, gradually increase size
  • Keep drill bit cool with water or compressed air
  • Avoid drilling too close to edges (minimum 3 inches)
  • Check for rebar or existing stress points
  • No, leave the blue plastic liner in place - it's designed to stay
  • The liner provides weather protection and is part of the railing system
  • Removing it may void your warranty and compromise durability
  • Only remove protective film from visible surfaces, not structural liners

Privacy Wall - Quick Code Checklist

Post Layout

  • Maximum 4.5 feet between posts (center to center)
  • Closer spacing may be required depending on height and wind load
  • Posts must handle 200 lb sideways load

Purpose & Limitations

  • Privacy walls are decorative/divider elements only
  • Cannot act as a fall protection system
  • Cannot be used as the primary guard on elevated decks

Privacy Wall Height

  • Aluminum Privacy wall heights vary between 36″ to 80″
  • Glass Privacy wall heights vary between 36″ to 72″
  • Cannot obstruct required guard height measurements
  • Does NOT replace required 42″ guard railing systems

Installation Requirements

  • Posts must be securely fastened to deck joists or blocking
  • Use structural fasteners: GRK 6″ structural screws recommended
  • Minimum 2 fasteners per post connection
  • Ensure blocking is properly installed beneath deck surface where needed
